A. Unwinding Parts

1) Type: 3" Air Shaft * 3 ea
2) Brake : Powder brake 5kg.m * 3 ea
3) Side Lay Winding Motor : 180W
(Speed Control Motor) * 2 ea
4) Side Lay Winding Clutch : 0.5kg.m * 2 ea

B. Slitting Parts

1) Type : Ring Knife Cutting system
2) Slitting Width : min. 21mm
3) Structure : Bottom Knife (Swing type)

C. Rewinding Parts

1) Drive : Powder Clutch 10kg.m * 2 ea
2) Air Shaft Type * 2 ea
3) Touch Roll : Auto & Manual Touch Roll * 2 ea
4) Trimming Winding Motor : 180W (Speed Control Motor)
5) Trimming Winding Clutch : 0.5kg.m * 1 ea

D. Frame

1) Main Size (m/m) : 1,800 * 1,850 * 1,720
2) Steel : 30t

E. Counter

1) Rotary encoder
